| 驱动类型 Drive type | 4X2 | 4X2 | ||
| 驾驶室类型 Cabin type | 单排 Single row | 单排 Single row | ||
| 轴距 Wheelbase | mm | 3360 | 3815 | |
| 制动方式 Brake type | 气刹 Air brake | 气刹 Air brake | ||
| 发动机参数Engine parameters | 型号 Model | 4HK1-TCG61 | 4HK1-TCG61 | |
| 排放标准 Emission standard | 国六 Euro VI | 国六 EURO VI | ||
| 排量 Displacement | ML | 5193 | 5193 | |
| 额定功率 Rated power | kW/（r/min） | 139 | 139 | |
| 最大扭矩/转速 Max torque/speed | N.m/（r/min） | 507/1600-2600 | 507/1600-2600 | |
| 变速箱 Gearbox | 型号 Model | 艾里逊1000型 Allison Model 1000 | 艾里逊1000型 Allison Model 1001 | |
| 速比 Speed ratio | 3.1，1.81，1.41，1，0.71，0.61/R4.49 | 3.1，1.81，1.41，1，0.71，0.61/R4.49 | ||
| 重 量 参 数 Weight specification | 整备质量 Curb weight | kg | 3240 | 3340 |
| 最大总质量 Maximum GVW | kg | 10550 | 10550 | |
| 载重 Payload | kg | 7310 | 7210 | |
| 前轴载荷 Front axle load | kg | 3500 | 3500 | |
| 后轴载荷 Rear axle load | kg | 7050 | 7050 | |
| 尺 寸 参 数 Size Parameters | 外形尺寸 Dimensions | 长mm(OL) Length | 5995 | 6980 |
| 宽mm Width | 2170 | 2170 | ||
| 高mm(OH) Height | 2350 | 2350 | ||
| 轮距 Wheelbase | 前轮距mm Front wheelbase | 1680 | 1680 | |
| 后轮距mm Rear wheelbase | 1650 | 1650 | ||
| 前悬 Front suspension | mm | 1110 | 1110 | |
| 后悬 Rear suspension | mm(ROH) | 2055 | 2055 | |
| 轮胎规格 Tire specifications | 235/75R17.5 16PR,245/70R19.5 16PR | 235/75R17.5 16PR,245/70R19.5 16PR | ||
| 性 能 参 数 Performance parameters | 最高车速 Maximum speed | km/h | 110 | 110 |
| 板簧 Leaf spring | 8/10+6 | 8/10+6 | ||
| 接近角 Approach angle | ° | 17 | 17 | |
| 离去角 Departure angle | °(α) | 19 | 19 | |
| 后桥速比 Rear axle ratio | 4.1 | 4.1 | ||
| 标配 Standard configuration | 收放机 Radio and television | ● | ● | |
| ABS系统 ABS system | ● | ● | ||
| 空调 A/C | ● | ● | ||
| 动力转向 Power steering | ● | ● | ||
| 面料座椅 Fabric seat | ● | ● | ||
| 直板钥匙 Straight plate key | ● | ● | ||
| 点烟器 Cigarette lighter | ● | ● | ||
| 选配 Optional configuration | 中控锁、电动窗 Central locking, electric windows | ○ | ○ | |
| 导流罩 Shroud | ○ | ○ | ||
| 真皮座椅 Leather seat | ○ | ○ | ||
| 前盘式制动器 Front disc brake | ○ | ○ | ||
| CD机 CD player | ○ | ○ | ||
| 限速装置(80公里/小时)Speed limiter (80 km/h) | ○ | ○ | ||
| 前盘式制动器 Front disc brake | ○ | ○ | ||
| MP5高配带倒车影像 MP5 high with reversing video | ○ | ○ | ||
| 倒车雷达 Reversing radar | ○ | ○ | ||
| 气悬座椅 Air Suspension Seat | ○ | ○ | ||
| 遥控钥匙 Remote key | ○ | ○ | ||
| MP5中配带倒车影像 MP5 with reversing video | ○ | ○ | ||
| 双油箱 Dual fuel tanks | ○ | ○ | ||
